High Quality Air Winch Hydraulic

air winch is a kind of single drum type air winch. It adopts

compressed air as its power to drive air motor, driving drum via gearbox

(to reduce transmitting speed and enlarge torque) so as to lift and drag

heavy cargo. Considering security, this winch is adopts disc air brake and

manual band brake. This winch is widely used for drilling platform,

marines, minings, engineering sites, etc. to pull heavy cargo.

Technical Parameters:

Working Air Pressure ++0.7-0.9 MPa

Rated Load(Top Layer) 50 kN

Rope Speed (At Rated Load) 0-12 m/min

Drum Diameter 345 mm

Wheel Diameter 620 mm

Drum Length 610 mm

Rope Capacity 19mm*160M

Motor Air Inlet Size Rc1 1/4″

Valve Exhaust Size Rc1 1/4″ and Rc1 1/2″

Brake Type Auto Disc Brake & Manual Band Brake

Emergency Stop & Overload Protection Yes with Extra fees

Rope Spooling Device Manual Type

Control Type Local Control Type

Safety Protection Drum Guard
