High Torque Air Motor

Lubricated Air Motors

Lubricated Air Motors are designed to thrive in harsher environments, as lubrication protects internal components and helps carry away smaller particulate which can evade filtration.

Stainless Steel Air Motors

Fully sealed and sanitary design, these corrosion resistant stainless steel Air Motors can be mounted in any plane with face or flange mounting options.

Non-Lubricated Air Motors

No lubrication necessary for these corrosion resistant air-motors. Hub and foot mounting options available and units can be mounted in any plane.

Gear Motors

By integrating a lubricated Air Motor with an inline or right angle gearbox, the resulting Gear Motor creates greater torque and slower output speed.

Why use a air motor

Variable Speed

You can var vary air motor speed between 300 and 10,000 rpm(depending on model selection) with a simple valve put I between the air source and air motor.

Non-electrical Sparking

As a non-electrical device, the possibility of explosion from ignoring flammable gases is greatly reduced.

Instantly Reversible

A four-way valve in the air line enables Air Motors to be instantly reversed. A turn of the valve causes a complete reversal of rotation, even when the motor is running at full speed.

Cool Running

As the air motor turns, expanded air cools the motor. Units can be used in ambient temperatures up to 250 degree F (120degree C) in a non-hazardous atmosphere.

Compact and Portable

Get maximum horsepower with minimum size and weight.

[How to Select an Air Motor]

Air motors differ in many ways from other power sources. These unique operating characteristics must be considered when selecting an air motor for a particular job. It is easy to change horsepower and speed of an air motor by throttling the air inlet. Therefor, the best rule of thumb for selecting an air motor is to choose one that will provide the horsepower and torque needed using only two-thirds (2/3) of the line pressure available. The full air line pressure will then be available for overloads and starting.
